| Product Technical Parameters |
| AC Parameters (Grid-connected) |
| Rated Power (kW) | 120 |
| Maximum Output Power (kW) | 132 |
| Rated Grid Voltage (V) | 380 |
| Permissible Grid Voltage | -15% to 15% |
| Rated Grid Frequency (Hz) | 50/60 |
| Permissible Grid Frequency Fluctuation (Hz) | ±5 |
| Power Factor | ±1 |
| THDI | <3% (at nominal power) |
| Connection Method | Three-phase Five-wire System |
| Full Power Charge and Discharge Conversion Time (ms) | <25 |
| AC Parameters (Off-grid) |
| Rated Output Voltage (V) | 380 |
| Rated Output Power (kW) | 120 |
| Rated Output Frequency (Hz) | 50/60 |
| THDU | <1% (resistive load) |
| Overload Capacity | 1.1 times long-term (at 45°C), 1.2 times for 1 minute |
| Battery Parameters |
| Cell Type | LFP-3.2V/280Ah |
| Battery Pack Configuration | 1P52S/46.592kWh |
| Battery System Configuration | 1P2605 |
| Battery Voltage Range (V) | 780-936 |
| Battery System Capacity (kWh) | 232.96 |
| Temperature Detection | Cell + Busbar + Liquid Cooling Plate |
| System Efficiency |
| Maximum Efficiency of Converter (%) | 97 |
| System Efficiency (%) | >87 (on the equipment side) |
| Charge and Discharge Rate | <0.5P |
| Protection |
| DC Input | Load Switch + Fuse |
| AC Protection of Converter | Circuit Breaker |
| AC Output Protection | Circuit Breaker |
| Overvoltage Protection | DC Type II/AC Type II |
| Fire Suppression System | Perfluorohexane |
| General Parameters |
| Dimensions (W*D*H) mm | 1000*1300*2250 |
| Weight (kg) | 2500 |
| Power Input Method | AC bottom entry |
| Ambient Temperature (°C) | -20°C to +55°C (power reduction at 50°C) |
| Ambient Humidity (%) | 0-100 |
| Operating Altitude (m) | 2000 |
| Protection Grade | IP55 |
| Cooling Method | Advanced Liquid Cooling |
| Communication |
| Communication Interface | Ethernet/RS485 |
| Communication Protocol | MODBUS-TCP/MODBUS-RTU/MQTT |
